This USB-C 80Gbps locking screw cable is designed for high-speed data, video and power connections in industrial cameras, machine vision systems, eGPU setups, capture cards, professional displays and other compatible USB-C equipment.
It features one straight USB-C male connector with a single locking screw and one side-angle USB-C male connector with a single locking screw. The angled connector helps with cable routing in compact installations, while the screw-lock design helps prevent accidental disconnection caused by vibration, movement or cable pull.
Key Features
• USB-C male to USB-C male high-speed cable
• Straight USB-C connector with single locking screw
• Side-angle USB-C connector with single locking screw
• Supplier-rated data transfer speed up to 80Gbps
• Supports up to 240W PD charging at 48V 5A with compatible equipment
• Supplier-rated video support up to 16K 60Hz
• Compatible with USB4 and Thunderbolt 3/4 equipment according to supplier specification
• Secure locking design for industrial and fixed installations
• Side-angle connector helps reduce cable bend in tight spaces
• Multi-layer shielded cable construction for stable high-speed transmission
• Reinforced strain relief for improved durability
• Available lengths: 0.3m, 1m and 2m
Ideal For
• Industrial and machine vision cameras
• External GPU and eGPU connections
• Video capture cards
• High-speed external storage
• Industrial PCs and servers
• Professional USB-C displays
• Laboratory and test equipment
• Laptop data, video and power connections
Compatibility
The locking screws require compatible threaded mounting points on your equipment. Please check the connector orientation, screw position and available installation space before ordering.
Maximum 80Gbps data speed, 240W charging and 16K video performance depend on the connected devices, ports, charger and supported protocol.
Package Contents
1 × USB-C male to male side-angle locking screw cable
