Create a neat, front-access USB-A connection point on dashboards, panels, enclosures, kiosks, and furniture with this USB 2.0 flush panel mount extension cable. The round, threaded panel socket provides a clean, professional finish and secures through a cut-out using the supplied locknut, while the internal USB-A male plug connects to your PC, charger, head unit, hub, or embedded system.
Ideal for adding a convenient USB port for charging and USB 2.0 peripherals such as flash drives, keyboards, mice, and service/programming access, without leaving loose cables on the front of your installation.
Key benefits:
-
Adds a front-facing USB-A port to panels and dashboards
-
USB-A female (panel mount) to USB-A male (internal) extension lead
-
Flush round mount for a professional, embedded finish
-
Threaded fixing with locknut for secure, vibration-resistant installation
-
Supports USB 2.0 data and power (host/device dependent)
Specifications:
-
Panel connector: USB Type-A Female (USB 2.0), flush mount socket
-
Cable connector: USB Type-A Male (USB 2.0)
-
USB standard: USB 2.0 (Hi-Speed up to 480Mbps)
-
Function: Data + power/charging (dependent on host/source)
-
Mounting: Threaded fixed mount with locking hardware
-
Colour/finish: Silver/white panel socket with black cable (as shown)
Notes:
