This Mini DisplayPort female to female panel mount cable is designed to provide a secure, fixed Mini DisplayPort connection for equipment panels, enclosures, PC cases, kiosks, and custom installations. The panel-mountable Mini DisplayPort female connector allows clean integration into front panels or faceplates, creating a reliable external display interface.
Supporting resolutions up to 4K (3840 × 2160) at 60Hz, the cable complies with DisplayPort 1.2 specifications and supports High Bit Rate 2 (HBR2) bandwidth up to 21.6 Gbps. It is backward compatible with DisplayPort 1.1 devices.
Constructed with high-quality copper conductors and gold-plated connectors, the cable ensures stable signal transmission and long service life. The low-profile connector design prevents blocking adjacent ports, while the molded strain relief reduces wear and stress in tight installations.
This cable is intended for Mini DisplayPort connections only and is not compatible with Thunderbolt ports or Thunderbolt extension applications.
Features
-
Mini DisplayPort female to Mini DisplayPort female panel mount cable
-
Supports 4K resolution up to 3840 × 2160
-
High Bit Rate 2 (HBR2) bandwidth up to 21.6 Gbps
-
DisplayPort 1.2 compliant, backward compatible with DP 1.1
-
Gold-plated connectors for improved signal integrity
-
Low-profile connector design for tight spaces
-
Molded strain relief for durability
-
0.3m cable length for compact installations
Compatibility
Works with Mini DisplayPort source and display devices including PCs, monitors, graphics cards, and professional AV equipment. Not compatible with Thunderbolt connections.
